Description
This custom Cat6 ethernet cable consists of a RJ45 male on one end and a RJ45 male on the other. It is typically used for ethernet network connections such as patch panels, switches and computers to routers.
TERMS: non-cancelable & non-returnable
| Physical Characteristics | |
|---|---|
| Colors Available | Black/Blue/Green/Grey/Red/White/Yellow |
| Connector Plating | Gold Plated 50 Micron |
| Cable Diameter | 6.2mm |
| Wire Gauge | 24AWG Solid |
| Shielding | F/UTP (100% Overall Mylar Foil Shielded Pairs) |
| Pairs | 4 |
| Fire Rating | CMR (FT4 Riser Rated) |
| Color Code | 568B |
| Temperature Rating | 75 Deg C |
| Jacket Type | PVC |
| Connectors | |
| Connector A | RJ45 Long Body Male |
| Connector B | RJ45 Long Body Male |
| Performance | |
| Frequency | 550 MHz |
| Approvals | |
| c(UL)us | Compliant - Cable |
| ETL Verified | Compliant |
| ANSI/TIA - 568 - C.2 | Compliant |
| ISO/IEC 11801 | Compliant |
| EN 50173-1 | Compliant |
| Environmental | |
| RoHS | Compliant |
| Reach | Compliant |
| Conflict Materials | Compliant |
| Package Information | |
| Package Quantity | 1 |
| Warranty Information | |
| Warranty | Limited Lifetime |
Spec Sheets
Lead-time
This item is assembled once an order is received.
All parts required to assemble this item are in stock and small quantities typically ship out within 1-2 business days.
For the lead-time on a larger quantity orders, please contact us via phone at
Product Weights
| SKU | Options | Weight |
| CAT6S-0.8BK | 8 inch / Black | 0.05 lb |
| CAT6S-0.8BL | 8 inch / Blue | 0.05 lb |
| CAT6S-0.8GN | 8 inch / Green | 0.05 lb |
| CAT6S-0.8GY | 8 inch / Grey | 0.05 lb |
| CAT6S-0.8RD | 8 inch / Red | 0.05 lb |
| CAT6S-0.8WH | 8 inch / White | 0.05 lb |
| CAT6S-0.8YL | 8 inch / Yellow | 0.05 lb |
| CAT6S-01BK | 1ft / Black | 0.07 lb |
| CAT6S-01BL | 1ft / Blue | 0.07 lb |
| CAT6S-01GN | 1ft / Green | 0.07 lb |
| CAT6S-01GY | 1ft / Grey | 0.07 lb |
| CAT6S-01RD | 1ft / Red | 0.07 lb |
| CAT6S-01WH | 1ft / White | 0.07 lb |
| CAT6S-01YL | 1ft / Yellow | 0.07 lb |
| CAT6S-02BK | 2ft / Black | 0.1 lb |
| CAT6S-02BL | 2ft / Blue | 0.1 lb |
| CAT6S-02GN | 2ft / Green | 0.1 lb |
| CAT6S-02GY | 2ft / Grey | 0.1 lb |
| CAT6S-02RD | 2ft / Red | 0.1 lb |
| CAT6S-02WH | 2ft / White | 0.1 lb |
| CAT6S-02YL | 2ft / Yellow | 0.1 lb |
| CAT6S-03BK | 3ft / Black | 0.15 lb |
| CAT6S-03BL | 3ft / Blue | 0.15 lb |
| CAT6S-03GN | 3ft / Green | 0.15 lb |
| CAT6S-03GY | 3ft / Grey | 0.15 lb |
| CAT6S-03RD | 3ft / Red | 0.15 lb |
| CAT6S-03WH | 3ft / White | 0.15 lb |
| CAT6S-03YL | 3ft / Yellow | 0.15 lb |
| CAT6S-04BK | 4ft / Black | 0.17 lb |
| CAT6S-04BL | 4ft / Blue | 0.17 lb |
| CAT6S-04GN | 4ft / Green | 0.17 lb |
| CAT6S-04GY | 4ft / Grey | 0.17 lb |
| CAT6S-04RD | 4ft / Red | 0.17 lb |
| CAT6S-04WH | 4ft / White | 0.17 lb |
| CAT6S-04YL | 4ft / Yellow | 0.17 lb |
| CAT6S-05BK | 5ft / Black | 0.2 lb |
| CAT6S-05BL | 5ft / Blue | 0.2 lb |
| CAT6S-05GN | 5ft / Green | 0.2 lb |
| CAT6S-05GY | 5ft / Grey | 0.2 lb |
| CAT6S-05RD | 5ft / Red | 0.2 lb |
| CAT6S-05WH | 5ft / White | 0.2 lb |
| CAT6S-05YL | 5ft / Yellow | 0.2 lb |
| CAT6S-06BK | 6ft / Black | 0.21 lb |
| CAT6S-06BL | 6ft / Blue | 0.21 lb |
| CAT6S-06GN | 6ft / Green | 0.21 lb |
| CAT6S-06GY | 6ft / Grey | 0.21 lb |
| CAT6S-06RD | 6ft / Red | 0.21 lb |
| CAT6S-06WH | 6ft / White | 0.21 lb |
| CAT6S-06YL | 6ft / Yellow | 0.21 lb |
| CAT6S-07BK | 7ft / Black | 0.24 lb |
| CAT6S-07BL | 7ft / Blue | 0.24 lb |
| CAT6S-07GN | 7ft / Green | 0.24 lb |
| CAT6S-07GY | 7ft / Grey | 0.24 lb |
| CAT6S-07RD | 7ft / Red | 0.24 lb |
| CAT6S-07WH | 7ft / White | 0.24 lb |
| CAT6S-07YL | 7ft / Yellow | 0.24 lb |
| CAT6S-08BK | 8ft / Black | 0.26 lb |
| CAT6S-08BL | 8ft / Blue | 0.26 lb |
| CAT6S-08GN | 8ft / Green | 0.26 lb |
| CAT6S-08GY | 8ft / Grey | 0.26 lb |
| CAT6S-08RD | 8ft / Red | 0.26 lb |
| CAT6S-08WH | 8ft / White | 0.26 lb |
| CAT6S-08YL | 8ft / Yellow | 0.26 lb |
| CAT6S-09BK | 9ft / Black | 0.24 lb |
| CAT6S-09BL | 9ft / Blue | 0.24 lb |
| CAT6S-09GN | 9ft / Green | 0.24 lb |
| CAT6S-09GY | 9ft / Grey | 0.24 lb |
| CAT6S-09RD | 9ft / Red | 0.24 lb |
| CAT6S-09WH | 9ft / White | 0.24 lb |
| CAT6S-09YL | 9ft / Yellow | 0.24 lb |
| CAT6S-10BK | 10ft / Black | 0.33 lb |
| CAT6S-10BL | 10ft / Blue | 0.33 lb |
| CAT6S-10GN | 10ft / Green | 0.33 lb |
| CAT6S-10GY | 10ft / Grey | 0.33 lb |
| CAT6S-10RD | 10ft / Red | 0.33 lb |
| CAT6S-10WH | 10ft / White | 0.33 lb |
| CAT6S-10YL | 10ft / Yellow | 0.33 lb |
| CAT6S-11BK | 11ft / Black | 0.32 lb |
| CAT6S-11BL | 11ft / Blue | 0.32 lb |
| CAT6S-11GN | 11ft / Green | 0.32 lb |
| CAT6S-11GY | 11ft / Grey | 0.32 lb |
| CAT6S-11RD | 11ft / Red | 0.32 lb |
| CAT6S-11WH | 11ft / White | 0.32 lb |
| CAT6S-11YL | 11ft / Yellow | 0.32 lb |
| CAT6S-12BK | 12ft / Black | 0.38 lb |
| CAT6S-12BL | 12ft / Blue | 0.38 lb |
| CAT6S-12GN | 12ft / Green | 0.38 lb |
| CAT6S-12GY | 12ft / Grey | 0.38 lb |
| CAT6S-12RD | 12ft / Red | 0.38 lb |
| CAT6S-12WH | 12ft / White | 0.38 lb |
| CAT6S-12YL | 12ft / Yellow | 0.38 lb |
| CAT6S-13BK | 13ft / Black | 0.44 lb |
| CAT6S-13BL | 13ft / Blue | 0.44 lb |
| CAT6S-13GN | 13ft / Green | 0.44 lb |
| CAT6S-13GY | 13ft / Grey | 0.44 lb |
| CAT6S-13RD | 13ft / Red | 0.44 lb |
| CAT6S-13WH | 13ft / White | 0.44 lb |
| CAT6S-13YL | 13ft / Yellow | 0.44 lb |
| CAT6S-14BK | 14ft / Black | 0.46 lb |
| CAT6S-14BL | 14ft / Blue | 0.46 lb |
| CAT6S-14GN | 14ft / Green | 0.46 lb |
| CAT6S-14GY | 14ft / Grey | 0.46 lb |
| CAT6S-14RD | 14ft / Red | 0.46 lb |
| CAT6S-14WH | 14ft / White | 0.46 lb |
| CAT6S-14YL | 14ft / Yellow | 0.46 lb |
| CAT6S-15BK | 15ft / Black | 0.5 lb |
| CAT6S-15BL | 15ft / Blue | 0.5 lb |
| CAT6S-15GN | 15ft / Green | 0.5 lb |
| CAT6S-15GY | 15ft / Grey | 0.5 lb |
| CAT6S-15RD | 15ft / Red | 0.5 lb |
| CAT6S-15WH | 15ft / White | 0.5 lb |
| CAT6S-15YL | 15ft / Yellow | 0.5 lb |
| CAT6S-16BK | 16ft / Black | 0.57 lb |
| CAT6S-16BL | 16ft / Blue | 0.57 lb |
| CAT6S-16GN | 16ft / Green | 0.57 lb |
| CAT6S-16GY | 16ft / Grey | 0.57 lb |
| CAT6S-16RD | 16ft / Red | 0.57 lb |
| CAT6S-16WH | 16ft / White | 0.57 lb |
| CAT6S-16YL | 16ft / Yellow | 0.57 lb |
| CAT6S-17BK | 17ft / Black | 0.64 lb |
| CAT6S-17BL | 17ft / Blue | 0.64 lb |
| CAT6S-17GN | 17ft / Green | 0.64 lb |
| CAT6S-17GY | 17ft / Grey | 0.64 lb |
| CAT6S-17RD | 17ft / Red | 0.64 lb |
| CAT6S-17WH | 17ft / White | 0.64 lb |
| CAT6S-17YL | 17ft / Yellow | 0.64 lb |
| CAT6S-18BK | 18ft / Black | 0.71 lb |
| CAT6S-18BL | 18ft / Blue | 0.71 lb |
| CAT6S-18GN | 18ft / Green | 0.71 lb |
| CAT6S-18GY | 18ft / Grey | 0.71 lb |
| CAT6S-18RD | 18ft / Red | 0.71 lb |
| CAT6S-18WH | 18ft / White | 0.71 lb |
| CAT6S-18YL | 18ft / Yellow | 0.71 lb |
| CAT6S-19BK | 19ft / Black | 0.78 lb |
| CAT6S-19BL | 19ft / Blue | 0.78 lb |
| CAT6S-19GN | 19ft / Green | 0.78 lb |
| CAT6S-19GY | 19ft / Grey | 0.78 lb |
| CAT6S-19RD | 19ft / Red | 0.78 lb |
| CAT6S-19WH | 19ft / White | 0.78 lb |
| CAT6S-19YL | 19ft / Yellow | 0.78 lb |
| CAT6S-20BK | 20ft / Black | 0.63 lb |
| CAT6S-20BL | 20ft / Blue | 0.63 lb |
| CAT6S-20GN | 20ft / Green | 0.63 lb |
| CAT6S-20GY | 20ft / Grey | 0.63 lb |
| CAT6S-20RD | 20ft / Red | 0.63 lb |
| CAT6S-20WH | 20ft / White | 0.63 lb |
| CAT6S-20YL | 20ft / Yellow | 0.63 lb |
| CAT6S-21BK | 21ft / Black | 0.7 lb |
| CAT6S-21BL | 21ft / Blue | 0.7 lb |
| CAT6S-21GN | 21ft / Green | 0.7 lb |
| CAT6S-21GY | 21ft / Grey | 0.7 lb |
| CAT6S-21RD | 21ft / Red | 0.7 lb |
| CAT6S-21WH | 21ft / White | 0.7 lb |
| CAT6S-21YL | 21ft / Yellow | 0.7 lb |
| CAT6S-22BK | 22ft / Black | 0.71 lb |
| CAT6S-22BL | 22ft / Blue | 0.71 lb |
| CAT6S-22GN | 22ft / Green | 0.71 lb |
| CAT6S-22GY | 22ft / Grey | 0.71 lb |
| CAT6S-22RD | 22ft / Red | 0.71 lb |
| CAT6S-22WH | 22ft / White | 0.71 lb |
| CAT6S-22YL | 22ft / Yellow | 0.71 lb |
| CAT6S-23BK | 23ft / Black | 0.72 lb |
| CAT6S-23BL | 23ft / Blue | 0.72 lb |
| CAT6S-23GN | 23ft / Green | 0.72 lb |
| CAT6S-23GY | 23ft / Grey | 0.72 lb |
| CAT6S-23RD | 23ft / Red | 0.72 lb |
| CAT6S-23WH | 23ft / White | 0.72 lb |
| CAT6S-23YL | 23ft / Yellow | 0.72 lb |
| CAT6S-24BK | 24ft / Black | 0.74 lb |
| CAT6S-24BL | 24ft / Blue | 0.74 lb |
| CAT6S-24GN | 24ft / Green | 0.74 lb |
| CAT6S-24GY | 24ft / Grey | 0.74 lb |
| CAT6S-24RD | 24ft / Red | 0.74 lb |
| CAT6S-24WH | 24ft / White | 0.74 lb |
| CAT6S-24YL | 24ft / Yellow | 0.74 lb |
| CAT6S-25BK | 25ft / Black | 0.77 lb |
| CAT6S-25BL | 25ft / Blue | 0.77 lb |
| CAT6S-25GN | 25ft / Green | 0.77 lb |
| CAT6S-25GY | 25ft / Grey | 0.77 lb |
| CAT6S-25RD | 25ft / Red | 0.77 lb |
| CAT6S-25WH | 25ft / White | 0.77 lb |
| CAT6S-25YL | 25ft / Yellow | 0.77 lb |
| CAT6S-30BK | 30ft / Black | 0.95 lb |
| CAT6S-30BL | 30ft / Blue | 0.95 lb |
| CAT6S-30GN | 30ft / Green | 0.95 lb |
| CAT6S-30GY | 30ft / Grey | 0.95 lb |
| CAT6S-30RD | 30ft / Red | 0.95 lb |
| CAT6S-30WH | 30ft / White | 0.95 lb |
| CAT6S-30YL | 30ft / Yellow | 0.95 lb |
| CAT6S-35BK | 35ft / Black | 1.1 lb |
| CAT6S-35BL | 35ft / Blue | 1.1 lb |
| CAT6S-35GN | 35ft / Green | 1.1 lb |
| CAT6S-35GY | 35ft / Grey | 1.1 lb |
| CAT6S-35RD | 35ft / Red | 1.1 lb |
| CAT6S-35WH | 35ft / White | 1.1 lb |
| CAT6S-35YL | 35ft / Yellow | 1.1 lb |
| CAT6S-40BK | 40ft / Black | 1.33 lb |
| CAT6S-40BL | 40ft / Blue | 1.33 lb |
| CAT6S-40GN | 40ft / Green | 1.33 lb |
| CAT6S-40GY | 40ft / Grey | 1.33 lb |
| CAT6S-40RD | 40ft / Red | 1.33 lb |
| CAT6S-40WH | 40ft / White | 1.33 lb |
| CAT6S-40YL | 40ft / Yellow | 1.33 lb |
| CAT6S-45BK | 45ft / Black | 1.4 lb |
| CAT6S-45BL | 45ft / Blue | 1.4 lb |
| CAT6S-45GN | 45ft / Green | 1.4 lb |
| CAT6S-45GY | 45ft / Grey | 1.4 lb |
| CAT6S-45RD | 45ft / Red | 1.4 lb |
| CAT6S-45WH | 45ft / White | 1.4 lb |
| CAT6S-45YL | 45ft / Yellow | 1.4 lb |
| CAT6S-50BK | 50ft / Black | 1.55 lb |
| CAT6S-50BL | 50ft / Blue | 1.55 lb |
| CAT6S-50GN | 50ft / Green | 1.55 lb |
| CAT6S-50GY | 50ft / Grey | 1.55 lb |
| CAT6S-50RD | 50ft / Red | 1.55 lb |
| CAT6S-50WH | 50ft / White | 1.55 lb |
| CAT6S-50YL | 50ft / Yellow | 1.55 lb |
| CAT6S-75BK | 75ft / Black | 2.26 lb |
| CAT6S-75BL | 75ft / Blue | 2.26 lb |
| CAT6S-75GN | 75ft / Green | 2.26 lb |
| CAT6S-75GY | 75ft / Grey | 2.26 lb |
| CAT6S-75RD | 75ft / Red | 2.26 lb |
| CAT6S-75WH | 75ft / White | 2.26 lb |
| CAT6S-75YL | 75ft / Yellow | 2.26 lb |
| CAT6S-100BK | 100ft / Black | 3.0 lb |
| CAT6S-100BL | 100ft / Blue | 3.0 lb |
| CAT6S-100GN | 100ft / Green | 3.0 lb |
| CAT6S-100GY | 100ft / Grey | 3.0 lb |
| CAT6S-100RD | 100ft / Red | 3.0 lb |
| CAT6S-100WH | 100ft / White | 3.0 lb |
| CAT6S-100YL | 100ft / Yellow | 3.0 lb |
| CAT6S-125BK | 125ft / Black | 5.0 lb |
| CAT6S-125BL | 125ft / Blue | 5.0 lb |
| CAT6S-125GN | 125ft / Green | 5.0 lb |
| CAT6S-125GY | 125ft / Grey | 5.0 lb |
| CAT6S-125RD | 125ft / Red | 5.0 lb |
| CAT6S-125WH | 125ft / White | 5.0 lb |
| CAT6S-125YL | 125ft / Yellow | 5.0 lb |
| CAT6S-150BK | 150ft / Black | 6.2 lb |
| CAT6S-150BL | 150ft / Blue | 6.2 lb |
| CAT6S-150GN | 150ft / Green | 6.2 lb |
| CAT6S-150GY | 150ft / Grey | 6.2 lb |
| CAT6S-150RD | 150ft / Red | 6.2 lb |
| CAT6S-150WH | 150ft / White | 6.2 lb |
| CAT6S-150YL | 150ft / Yellow | 6.2 lb |
