RG6 18AWG Solid Copper Covered Steel 60% AL Braid + 100% Foil 75 Ohm CMR Bulk Cable - Black

Coax Bulk CableSKU: BK-RG640-BK-250

Length: 250ft
Color: Black
Price:
Sale price$36.40 CAD
Stock:
In stock


Description

This bulk RG6 cable consists of a 18AWG solid center conductor. It is ideal for CATV video applications.

Physical Characteristics
Cable Lengths Available 250 foot
1000 foot Pull Box
Color Black
Cable Diameter 6.90mm
Wire Gauge 18AWG
Inner Conductor 1/1.02mm Copper Clad Steel - Oxygen-Free
Insulation 4.57mm Foamed Polyethylene
Shield 1 Bonded Aluminum Foil
Shield 2 5*16*0.12mm 60% AL
Jacket Material PVC - Polyvinyl Chloride
Jacket Rating CMR/FT4 [Riser Rated]
Impedance 75±3Ω
Capacitance 54±3pF/m
Return Loss 20dB Min
Operating Temperature -20℃ ~ 75℃
Approvals
c(ETL)us Yes
Environmental
RoHS Yes
Packaging Information
Package Quantity 1

Cable Length

Product Weight

1000ft [305m]

28.33 lbs[12.85 kg]

250ft [76.2m]

7.08 lbs[3.21 kg]

SKU Options Weight
BK-RG640-BK-250 250ft / Black 7.25 lb
BK-RG640-WH-250 250ft / White 7.25 lb
BK-RG640-BK 1000ft / Black 29.0 lb
BK-RG640-WH 1000ft / White 29.0 lb
