Description
This premium stereo audio cable has a 4.4mm male on both ends. It is typically used to connect pro audio equipment with balanced Bantam TT jacks. It can also be used with balanced TT patch bays.
- Hi-flex balanced cable is used to capture all highs & lows for optimum audio performance
- Neutrik NP3TT-PB plugs for rugged durability and efficient signal transfer
- Braided shield surrounds center conductors for maximum EMI/RFI noise rejection therefore maintaining the cleanest signal possible
- Multi-stranded copper center conductors and a durable cable jacket are ultra flexible to maximize mobility
- Oxygen-Free Copper (OFC) conductors for enhanced signal clarity
- FT4 riser fire rated jacket for in-wall use
- Lead Free, "silver laced" solder is used in order to reduce loss and maximize conductivity
Physical Characteristics | |
---|---|
Color | Black |
Connector Plating | Nickel |
Cable Diameter | 5mm |
Wire Gauge | 24AWG |
Jacket Material | PVC - Polyvinyl Chloride |
Fire Rating | FT4 (Riser CMR) |
Cable Shielding | 90% Bare Copper Braid |
Strain Relief | Molded PVC |
Connectors | |
Connector A | 4.4mm Stereo Male |
Connector B | 4.4mm Stereo Male |
Approvals | |
cUL | Yes - Cable |
Environmental | |
RoHS | Yes |
Package Information | |
Package Quantity | 1 |
Warranty Information | |
Warranty | Limited Lifetime |
1.5ft | 3ft | 6ft | 10ft | 15ft | 25ft | 35ft | 50ft |
---|---|---|---|---|---|---|---|
0.30 lbs | 0.35 lbs | 0.45 lbs | 0.55 lbs | 0.70 lbs | 1.00 lbs | 1.30 lbs | 1.75 lbs |
Spec Sheets
Lead-time
This item is assembled once an order is received.
All parts required to assemble this item are in stock and small quantities typically ship out the same business day or the next business day.
For the lead-time on a larger quantity orders, please contact us via phone at
Product Weights
SKU | Options | Weight |
BMTT1-01.5 | 1.5ft | 0.11 lb |
BMTT1-03 | 3ft | 0.19 lb |
BMTT1-06 | 6ft | 0.34 lb |
BMTT1-10 | 10ft | 0.53 lb |
BMTT1-15 | 15ft | 0.77 lb |
BMTT1-25 | 25ft | 1.25 lb |
BMTT1-35 | 35ft | 1.73 lb |
BMTT1-50 | 50ft | 2.45 lb |
