OM4 Multimode 50 Micron Indoor/Outdoor (Corning ClearCurve) - OFNR Riser Fiber Bulk Cable (per meter)

OM4 Multimode Bulk CableSKU: BK-F6IO-OM4-R-T

Fiber Count: 6-Strand
Price:
Sale price$3.32 CAD
Stock:
In stock

This item does not qualify for free shipping.



Description

This bulk OM4 fiber cable is indoor/outdoor riser rated and has a tight buffer construction. It is OFNR rated for riser and general inside plant environments. It also has a UV stabilizer for protection against exposure to the sun.

Features

  • 900µm Tight Buffers
  • Water blocking aramid yarn strength members
  • UV resistant jacket, OFNR rated construction
  • Corning ClearCurve OM4 optical fibers
  • Jacket print ensures product identification and fiber compatibility
  • Durable jacket offers added protection during installation and in rugged use applications

Specifications

Physical Characteristics
Color Black
Fiber Optic Type OM4 50 micron Multimode OFNR Riser Indoor/Outdoor Tight Buffered Cable
Fiber Count 6-Strand/ 12-Strand
Glass Fiber
Corning ClearCurve
Sub Unit Diameter 900 Micron
Nominal Diameter

4.8mm (6-Strand)

5.8mm (12-Strand)

Bending Radius (Installation)

72mm (6-Strand)

87mm (12-Strand)

Bending Radius (Operation)

48mm (-Strand)

58mm (12-Strand)

Pulling tension

300lbs

Operating Temperature -40°C ~ +70°C
Storage Temperature -40°C ~ +70°C
Performance
Wavelength 850nm / 1300nm
Attenuation Max. 3.0dB/km @850nm
1.0dB/km @1300nm
Link Length

550m (10Gbps @850nm)

Bandwidth (EMB High Performance) 4700MHz.km @850nm
Fire Rating OFNR Riser
Certification(s)
UL Yes
Product Support
RoHS Yes
Country of Origin USA
SKU Options Weight
BK-F6IO-OM4-R-T 6-Strand 0.12 lb
BK-F12IO-OM4-R-T 12-Strand 0.12 lb
