This cable is primarily used in the assembly of duplex fiber patch cords used in server rooms, data centers and other point to point indoor applications.
Physical Characteristics |
Color |
Orange |
Fiber Optic Type |
Zipcord 3.0 Multimode 62.5/125 micron |
Fiber Core Diameter |
50 micron ± 3.0 micron |
Bandwidth Range |
@850 > 160 MHz/km @1310 > 500 MHz/km |
Attenuation Range |
@850nm 3.0dB/km @1310nm 1.0dB/km |
Maximum Tensile Load |
Short Term, N 500 Long Term, N 300 |
Minimum Bending Radius |
Load 50mm Unload 30mm |
Fiber Count |
2C |
Tight Buffer Diameter |
0.9 micron ±0.05 |
Cable Diameter |
3mm |
Fire Rating |
LSZH jacket meet IEC 60332-3C and OFNR |
Uniformly Distributed |
Kevlar |
Operating Temperature |
-20 ℃ ~ +60 ℃ |
Environmental |
RoHS |
Yes |
