5MP PTZ IP Camera - 2.7~13.5mm - 5x Optical Zoom - Two-Way Audio - Indoor - White

Phantom IP Cameras & RecordersSKU: SC-6252W-5X-PTZ

Price:
Sale price$711.45 CAD

Contact sales to place an order, 1-866-207-6442 or sales@infinitecables.com.



Description

Overview

This 5MP PTZ indoor IP based dome camera provides sharp, high definition images in daylight or nighttime settings. The camera has a focal length of 2.7 mm to 13.5mm lens with 5x optical zoom which delivers 106.9 ° to 30.6 ° horizontal field of view. Its maximum resolution is 2880 x 1620 at 30 fps and supports Ultra 265 video compression technology, which assures savings in bandwidth and storage. The camera is IP based with integrated PoE technology which makes for a quick and easy installation over a single CAT5e/CAT6 cable. It has 98 feet of IR range using an IR cut filter and IR LEDs.

Features

  • High quality image with 5MP,1/2.7" CMOS sensor
  • 2880*1620@30fps in the main stream, 16:9 aspect ratio
  • Ultra 265, H.265, H.264, MJPEG
  • 5X optical zoom allows for closer viewing of subjects
  • Smart intrusion prevention, support false alarm filtering, include Cross Line, Intrusion, Enter Area, Leave Area detection
  • Face capture, automatic selection of best snapshots
  • Light Hunter technology ensures ultra-high image quality in low illumination environment
  • Up to 120 dB Optical WDR (Wide Dynamic Range)
  • Wi-Fi connection and easy installation
  • Built-in Mic & Speaker, supports two-way audio
  • Alarm 1 in and 1 out
  • Smart IR, up to 30m (98 ft) IR distance

Application

The typical application for most security cameras networks is to connect the IP cameras to a NVR/DVR for simplified playback and additional storage space. Alternatively you can use an IP cameras as a standalone camera and not part of a network by connecting it directly to a POE switch and save the recording on a micro SD card.

NVR Setup



Standalone Camera Setup

Specifications

Camera
Image Sensor 1/2.7" (5 MP) progressive scan CMOS
Minimum Illumination Color: 0.003 lux @ (F1.2, AGC on)
0 Lux with IR
Day/Night IR-cut filter with auto switch (ICR)
Shutter Auto/Manual, 1 ~ 1/100000s
S/N >56dB
WDR 120dB
Lens
Lens Type 2.7~13.5mm@F1.2, AF automatic focusing and motorized zoom lens
Iris Auto aperture
Angle of View (H) 106.9°~30.6°
Angle of View (V) 56.0°~17.7°
Angle of View (O) 131.5°~39.8°
DORI
DORI Distance 2.7mm Lens, 70.9m(232.5ft) Detect, 28.4m(93.0ft) Observe, 14.2m(46.5ft) Recognize, 7.1m(23.3ft) Identify

13.5mm Lens, 247.5m(812.0ft) Detect, 99.0m(324.8ft) Observe, 49.5m(162.4ft) Recognize, 24.8m(81.2ft) Identify
Illuminator
IR Range Up to 30m (98ft) IR Range
Wavelength 850nm
IR On/Off Control Auto/Manual
Video
Video Compression Ultra 265, H.265, H.264, MJPEG
Frame Rate Main Stream: 5MP (2880*1620),Max 30fps;
Sub Stream: 720P (1280*720), Max 30fps;
Third Stream: D1 (720*576), Max 30fps
Video Bit Rate 128 Kbps~16 Mbps
U-code Supported
OSD Up to 8 OSDs
Privacy Mask 24 areas, up to 4 areas per scene
ROI Supported
Video Stream Triple streams
White Balance Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
Digital Noise Reduction 2D/3D DNR
Smart IR Supported
Flip Normal/Flip Vertical/Flip Horizontal/180°
HLC Supported
BLC Supported
Defog Digital Defog
Intelligent
Smart Intrusion Prevention Support false alarm filtering: Line crossing detection, Intrusion detection, Enter Area detection, Leave Area detection
Face Capture Support
Events
Basic Detection Motion detection, Tampering alarm, Audio Detection
General Function Watermark, IP Address Filtering, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication
Audio
Audio Compression G.711U, G.711A
Audio Bitrate 64 Kbps
Two-Way Audio Supported
Suppression Supported
Sampling Rate 8KHz
Storage
Edge Storage Micro SD, up to 256GB
Network Storage ANR, NAS(NFS)
Network
Protocols IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP, SSL/TLS
Compatible Integration ONVIF (Profile S, Profile G, Profile T), API, SDK
User/Host Up to 32 users. 2 user levels: administrator and common user
Security Password protection, strong password, HTTPS encryption, basic and digest authentication for RTSP, digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF
Client EZStation
EZView
EZLive
Web Browser Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below
Pan & Tilt
Pan Range 350° (endless)
Pan Speed 0.1°/s ~ 200°/s
Preset speed: 60°/s
Tilt Range 0° ~ 90°
Tilt Speed 0.1° ~ 50°/s
Preset speed: 50°/s
Number of Presets 1024
Preset Patrol 16 patrols, up to 64 presets for each patrol
Patrol Stay Time 15s~1800s
Preset Image Freeze N/A
Home Position Supported
Interface
Audio I/O N/A
Alarm I/O 1/1
Serial Port 1 RS485
Built-In Mic Supported
Built-In Speaker Supported
WIFI
Support (IEEE802.11b/g/n)
Network 1 * RJ45 10M/100M Base-TX Ethernet
Video Output N/A
Certification
EMC FCC Part 15
EN 55032:2015
EN 55024:2010
EN 61000-3-2:2014
EN 61000-3-3-2013
Safety IEC 62368-1
EN 62368-1
UL 60950-1
Environment CE-ROHS (2011/65/EU;(EU)2015/863);
WEEE (2012/19/EU);
REACH (Regulation (EC) No 1907/2006)
NDAA Compliant Yes
General
Power DC12V(±25%),
PoE (IEEE 802.3af, Mode B – Pins 4, 5, 7 and 8)
Power consumption: MAX 15W
Power Interface Ø 5.5mm coaxial power plug
Dimensions
(Ø x H)
Φ129 x 143.6mm (Φ5.1€™€™ x 5.7€™€™)
Weight 0.76kg(1.67lb)
Working Environment/Storage Environment -10„ƒ~50„ƒ(14°F ~ 122°F),Humidity: ‰¤95% RH (non-condensing)

-40„ƒ~70„ƒ(-40°F ~ 158°F),Humidity: ‰¤95% RH (non-condensing)
Surge Protection 4KV
Reset Button Supported
Protection Ingression protection: N/A
Vandal resistant: N/A

Quick Start Guide

User Manual

Phantom Camview for Android

Phantom Camview iOS App
Supports iOS 8.0 or later & requires macOS 11.0 or later and a Mac with the Apple M1 chip or later. Compatible with iPhone, iPad, iPod touch and Mac.

PhantomCamTools Windows app

PhantomCamStation Windows app to set up cameras

3-YEAR WARRANTY

Infinite Cables Inc. offers a 3-year warranty on all cameras and hard drives to be free from defects in material and workmanship.

This warranty is available to the original purchaser with proof of purchase. This warranty does not apply to any damage or product failure that is caused beyond Infinite Cables’ control, including but not limited to, misuse, neglect, accidental damage, improper installation or application, alteration, acts of God, or normal wear and tear. Infinite Cables is not responsible for any costs of removal or installation. Infinite Cables’ sole and exclusive obligation under this warranty shall be limited to repair or replacement of the defective item at our discretion.

Infinite Cables makes no other warranties expressed or implied including without limitation and warranty of fitness for a particular purpose. Infinite Cables will not be liable for damages of any kind including lost or anticipated profits, delay, consequential or special damages.

SKU Weight
SC-6252W-5X-PTZ 1.3 lb
